110mm-138mm QL40 Hammer Parts Anti-Friction For Water Well Drilling
Place of Origin: China
Brand Name: MSD
Certificate: ISO9001
Model Number: QL 40
Payment & Shipping Terms:
Price: Negotiable
Delivery Time: 10-25 days
Payment Terms: T/T west union L/C
Supply Ability: 5000 pcs per one month pieces per month
Email This Page Contact Now
- Product Description
- 1 Working Pressure:: 1.2-2.0Mpa
- 2 Bits Dia. Fitted:: 110mm-138mm
- 3 Air Consuption:: 1.0-2.4Mpa
- 4 Product Name:: DTH Hammer Drill Bit Dth Hammer
- 5 Size:: 4 Inch
- 6 Type:: QL40 Shank
- 7 Certification:: ISO9001
110mm-138mm QL40 Hammer Parts Anti-Friction For Water Well Drilling
QL40 Hammer are used for high air pressure mining DTH Hammer blast hole drilling and water well drilling project.Working with DTH drilling pipe and DTH Drill Bit, mainly applied in Mining,Marble quarry or well drilling and other construction projects.
More Information except QL40 Hammer:
Bit size | Shank type | Recommended DTH bits diameter |
3.5”/3” DTH hammer bits | COP34, DHD3.5, MISSION30, BR3 shank | 90mm~ 105mm |
4” DTH hammer bits | DHD340, QL40, MISSION40, SD4 shank | 110mm~ 130mm |
5” DTH hammer bits | DHD350, QL50, MISSION50, SD5 shank | 134mm~ 152mm |
6” DTH hammer bits | DHD360, QL60, MISSION60, SD6 shank | 152mm~ 203mm |
8” DTH hammer bits | DHD380, QL80, MISSION80, SD8 shank | 203mm~ 305mm |
12” DTH hammer bits | DHD112, SD12 and QL120 shank. | Available upon to customers’ request
|
-
